0036 1 406 98 08
SKU
SDO-502
Automatic door opener with application - push arm - 100 kg-
€405.00
Description
The SDO-502 automatic door opener is suitable for doors weighing up to 100 kg and with a width of 810-1200 mm. It provides a durable and straightforward solution for barrier-free access in shops, offices, and residential entrances. The device features a 24V DC power output with a load capacity of 0.5A. Its aesthetic, powder-coated cover gives it an elegant appearance, while its self-learning control and anti-pinch mechanism ensure easy and safe operation. It is highly programmable and supports connections for an uninterruptible power supply, photocell, motion sensor, push button, code keypad, and card reader.
Downloads
More Information
| Voltage (V) | 230 V |
|---|---|
| Voltage type | AC |
| Power source capacity (A) | 3A @ 24V DC |
| Motor torque | 45 Nm |
| Parameters of a movable door leaf | 45 kg/1200 mm <-> 100 kg/800 mm |
| Opening and closing time | adjustable |
| Opening speed | 1-5 grade |
| Closing speed | 1-5 grade |
| Reclosure delay | 1-255 s |
| Maximal opening angle | 120° |
| Programming | mobil application |
| Opening possibilities | controlled electrical signal, (NO - dry contact) |
| Behaviour (in case of power off) | freely movable in the case of a fail-safe electric lock |
| Operating modes | Always open, automatic opening, single open-close, full lock mode |
| Adjustable operating mode | via application, by short-circuiting the appropriate legs |
|---|---|
| Other functions | uninterruptable, interlock system, synchronized operation, self-learning, obstacle detection |
| Dimension of body | 532 x 74,2 x 70 mm |
| Arm size and type | 392 mm, scissor arm |
| Mounting | surface mounted, above the door |
| Recommended use | in the case of outward opening doors |
| Installation area | indoor |
| Package contents | door operator, mounting bracket, screw set, scissor arm |
| Compatible products | electric lock(24V DC @ 0,5A), access control system, IR sensor, combined sensor (IR and microwawe) |
| IP rating | unclassified |
| Environmental temperature | -20°C ~ +60°C |
| Gross weight | 5,5 kg |
| Warranty | 12 months |
| Certificates | CE |
| Product category | D |
