0036 1 406 98 08
SKU
BXB-E10DZ04-or-S6
Barrier E10 - orange - straight arm - 6 m - reversible
€763.00
Description
|
The E10 ECO 85 type 150W power barriers with low consumption are designed for medium-traffic areas, with the precision servomotor and spring balancing guaranteeing 4 million opening/closing cycles (MCBF), thus completing 1200 cycles per day without any issues. The control unit with an LCD display helps in the simple and quick setup of the gate. The modern exterior casing is aesthetically pleasing and provides protection against weather conditions. The internal mechanism can be highlighted, allowing it to be easily converted from right-handed to left-handed or vice versa. The E10 is a modern, easily installable, precisely adjustable automatic barrier. The device operates with a servomotor, which allows for precise positioning of the arm, as well as adjustment of the open time and opening speed.
|
Downloads
More Information
| Voltage (V) | 230 V |
|---|---|
| Voltage type | AC |
| Motor type | DC servo (brushless) |
| Motor power (W) | 150 W |
| Motor torque | 240 Nm |
| Opening direction (DIN 107) | reversible (right< >left) |
| Body design | powder coated, e10grey body, orange door |
| Dimension of body | 335 x 960 x 290 mm |
| Arm size and type | 6 m straight |
| Arm cross section | 45 x 100 mm |
| Height with open arms | ~ 6,9 m |
| Product family | E10 (ECO 85) |
| Opening and closing time | 3-5 s (adjustable) |
| Automatic closeure | adjustable |
| Reclosure delay | 0 sec / 3-60 s |
| Programming | digitally from controller |
| Opening possibilities | controlled electrical signal, (NO - dry contact), remote control, manual opening (in state of power off) |
| Communication | RS-485 |
| Passing speed | 125 open/hour (40% working cycle) |
|---|---|
| End position setting | from control electronics (horizontally and vertically) |
| Built-in LED | small LED on the door |
| ATTENTION! | The remote control transmitter-receiver found in the device is recommended for maintenance purposes only. |
| Package contents | barrier, counterbalancing springs, barrier arm, remote control |
| Counterbalancing springs | BXB-SPRE1-25042-4.5-rd, BXB-SPRE1-27045-5.5-bl |
| Compatible products | protective rubber, LED strip, barrier arm support (fix), operation light, traffic light, induction loop, photocell, remote control module, BXC-SPIDER - RS485 communicator |
| Required accessories for a mobile arm support / protection rubber | For the separate installation of the arm support or LED and edge protection rubber, the 5.5 blue spring must be replaced with a 6.8 yellow spring. For combined installation, the 4.5 blue spring must be replaced with a 6.8 yellow spring. |
| Recommended use | medium use |
| Installation area | outdoor |
| Life time | MCBF: 4 million opening cycles |
| IP rating | IP54 |
| Environmental temperature | -35°C ~ +80°C |
| Humidity tolerance (non-condensing) | >90% |
| Gross weight | 48,5 kg |
| Warranty | 12 months |
| Certificates | CE |
| Manufacturer | BOOMX |
| Product category | B |
