QK-E400KIT(V2)
Double swing gate kit - EON
€525.00
Description
The QK-E400KIT swing gate operator set is part of the QUIKO EON family, designed for residential use. The gate motor operates on 230V AC power and is suitable for moving wings up to 4 meters long or with a maximum weight of 700 kg*.
The motor's compact housing allows installation even in spaces where available room is limited. The motors automatically lock the doors closed** and can be manually opened in case of an emergency.
 |
Thanks to the high-quality materials used, the EON wing gate operator product family requires minimal maintenance and offers high resistance and durability.
*= The parameters listed are maximum limits, which should be interpreted separately. Detailed specifications can be found in the properties section and on the datasheet.
**= For wings longer than 1.8 meters, installing an electric lock is recommended.
Downloads
More Information
| Voltage (V) | 230 V |
|---|---|
| Voltage type | AC |
| Maximum current consumtion (A) | 0,9 - 1,5 A |
| Motor type | AC (asynchronous) |
| Motor power (W) | 350 W |
| Motor torque | max. 2200 N |
| Control board | QK-CE2204UNISW |
| Capacitance of the capacitor | 8 µF |
| Parameters of a movable gate leaf | 700 kg/2 m <-> 300 kg/4 m |
| Maximum gate width | 4 m |
| Maximal gate weight | 700 kg |
| Working cycle | 40% (for low usage) |
| Controlled output type | voltage output (auxiliary power, lamp) |
| Controlled output current rating | aux. power supply - 9,6W (24V DC @ 400mA), lamp - 20W (24V DC @ 834mA) |
| Obstacle detection inputs | opening (internal) photocell (adjustable - NO/NC) , closing (external) photocell (adjustable - NO/NC) |
| Opening time | 20 sec |
| Reclosure delay | 0-99 s |
| Maximal opening angle | 90°/100° (determined by installation) |
| Programming | digitally from controller |
|---|---|
| Opening possibilities | controlled electrical signal, (NO - dry contact), (NO - dry contact, <1s), remote control |
| Behaviour (in case of power off) | fail-secure, can be mechanically opened with a key |
| Operating modes | full opening, partial opening, fast closing, pedestrian gate |
| Other properties | - overheat protection (150°C), - semi-automatic movement path learning with remote control (opening/closing time, automatic closing) - adjustable speed, motor strength and operating mode (full opening, part opening, fast closeure, pedestrian gate), - digitally programmable outputs - "cold winter" and "kick-back" function - "single-leaf" and condominium mode - opening cycle counting, Error log feedback via display |
| Dimension of body | 740 x 87 x 190 mm |
| Stroke length | 400 mm |
| Product family | EON - swing gate, durable design |
| Installation area | outdoor |
| Mounting | surface mounted |
| Recommended use | for swing gates, for small-sized columns, residental usage |
| Package contents | 2 gate operators, 1 control board, 1 lamp, 1 pair of NC IR photocells, 2 remote controls, 2 emergency release keys |
| Compatible products | QK-LUX24LED (lamp), QK-BRALUX ("L" mounting bracket for the lamp), QK-M04 (remote control), QK-FTPO (photocell), QK-AN433-V4 (antenna), QK-MODRAL4 (external antenna modul), QK-ELOCKM (pulse control module - 12V DC @ 0,3/2A), QK-ELOCKM330 (pulse control module - 12V DC @ 0,5/4A), QK-RELAY (24V external relay - 230V @ 7A), QK-BRAE400 (screwable mounting bracket) |
| IP rating | IP44 |
| Environmental temperature | -30°C ~ +70°C |
| Warranty | 48 months* |
| Certificates | CE |
| Manufacturer | QUIKO |
| Product category | F |
