QK-R400BKIT(V2)
Double swing gate kit - ROTELLO
€750.00
Description
The QK-R400BKIT(V2) wing gate operator set is part of QUIKO's more powerful ROTELLO family, designed for residential use. The gate motor operates on 24V DC power, is compatible with an uninterruptible power supply (UPS), and is suitable for moving wings up to 4.5 meters long or with a maximum weight of 600 kg.*
ROTELLO gate operators feature an die-cast, powder-coated housing, as well as an extremely resistant steel and bronze mechanism. This design ensures quiet, reliable, and maintenance-free operation. The motors automatically lock the doors closed and can be manually opened in case of an emergency.**
Thanks to the high-quality materials used, the ROTELLO wing gate operator product family requires minimal maintenance and offers high resistance and durability.
*= The parameters listed are maximum limits and should be interpreted separately. Detailed specifications can be found in the properties section and on the datasheet.
**= For wings longer than 1.8 meters, installing an electric lock is recommended.
More Information
| Voltage (V) | 24 V |
|---|---|
| Voltage type | DC |
| Maximum current consumtion (A) | 8 A (1,7 - 6,64 A) |
| Motor type | DC stepper motor |
| Motor power (W) | 160 W |
| Motor torque | max. 2000 N |
| Control board | QK-CE24BATRA |
| Parameters of a movable gate leaf | 600 kg/2 m <-> 300 kg/4,5 m |
| Maximum gate width | 4,5 m |
| Maximal gate weight | 600 kg |
| Working cycle | 100% (for continuous usage) |
| Controlled output type | voltage output (auxiliary power, lamp, electric lock) |
| Controlled output current rating | aux. power supply - 3W (12V DC @ 250 mA), lamp - 24W (24V DC @ 1 A), electric lock - 48W (24V DC @ 2 A) |
| Obstacle detection inputs | opening (internal) photocell (adjustable - NO/NC) , closing (external) photocell (adjustable - NO/NC) |
| Opening time | 18 sec |
| Reclosure delay | 0-99 s |
| Body design | powder-coated housing with an extremely resistant steel and bronze mechanism. |
| Maximal opening angle | 90°/100° (determined by installation) |
| Programming | digitally from controller |
| Opening possibilities | controlled electrical signal, (NO - dry contact), (NO - dry contact, <1s), remote control |
|---|---|
| Behaviour (in case of power off) | fail-secure, can be mechanically opened with a key |
| Operating modes | full opening, partial opening, fast closing, pedestrian gate |
| Other properties | - UPS capable - automatic movement path learning (opening/closing time) - adjustable speed - adjustable slowdown and obstacle detection level with potentiometer - quick remote control programming (even, - adjustable operating modes - "single-leaf" mode - adjustable electric lock output |
| Battery charging current | 0,1A (24V) |
| Dimension of body | 770 x 105 x 153 mm |
| Stroke length | 400 mm |
| Product family | ROTELLO - swing gate, durable design |
| Installation area | outdoor |
| Mounting | surface mounted |
| Recommended use | for swing gates, for large-sized columns, strudy residential use |
| Package contents | 2 gate operators, 1 control board, 1 lamp, 1 pair of NC IR photocells, 2 remote controls, 2 emergency release keys |
| Compatible products | QK-LUX24LED (lamp), QK-BRALUX ("L" mounting bracket for the lamp), QK-M04 (remote control), QK-FTPO (photocell), QK-AN433-V4 (antenna), QK-FCR400 (mechanical end-limit stop) |
| IP rating | IP54 |
| Gross weight | -30°C ~ +70°C |
| Warranty | 48 months* |
| Certificates | CE |
| Manufacturer | QUIKO |
| Product category | F |
