0036 1 406 98 08
SKU
BMTV-539(V4)
Full-height turnstile - semi automat - 1 lane - outdoor
€7,853.00
Description
Turnstile gates are designed for access control to high security areas. Turning the bars is only possible after swiping a card with the appropriate authorization, similar to a turnstile, but unlike a turnstile, you cannot climb over or crawl under the bars, so you can even use a turnstile for unattended access.
The BMTV-539(V2) is a single lane semi-automatic turnstile gate that provides bi-directional access. Its aesthetic INOX metal construction gives it a stylish appearance and timeless use. Thanks to its fail-safe solution, in the event of a power failure, the grids can rotate freely to allow passage.
It can also be installed outdoors and is more resistant to environmental conditions thanks to its IP55 protection.
Materials needed for maintenance:
 |
 |
 |
 |
|
BER-FEKTISZTITO Brake cleaner spray 500ml |
BER-INOXAPOLO Stainless steel maintenance spray 400ml |
BER-UNISPRAY6+ Universal spray 400ml |
BER-HLS500 Lubricant spray 500ml |
Downloads
More Information
| Voltage (V) | 230 V |
|---|---|
| Voltage type | AC |
| Consumption (W) | 30 W |
| Body design | brushed INOX |
| Dimensions | 1630 x 2300 1580 mm |
| Wing size and type | ~ 1950 x 640 mm (modular) |
| Return by springs | yes (helps to take position) |
| Lockable? | automatically after rollover |
| Product family | semi-automat, one passage turnstile (full height) |
| Automatic closeure | with DIP switch (default 9s) |
| Reclosure delay | 5-12 s |
| Opening possibilities | controlled electrical signal, (NO - dry contact, <1s) |
| Communication | RS-485 |
| Passage direction | one-way/two-way |
| Passing speed | 25-30 persons/min |
| Passing width | ~ 640 mm |
|---|---|
| Emergency mode | in case of a power outage, the wing rotates freely |
| Built-in LED | side (dynamic) |
| Package contents | parts of the full-height turnstile, fixing screws (in concrete) |
| Compatible products | remote control module, BXC-SPIDER - RS485 communicator |
| Recommended use | medium traffic areas |
| Installation area | indoor, outdoor |
| Life time | MCBF: 0,5 million turnovers |
| IP rating | IP55 |
| Environmental temperature | -25°C ~ +70°C |
| Humidity tolerance (non-condensing) | >95% |
| Gross weight | 310 kg |
| Warranty | 12 months |
| Certificates | CE |
| Manufacturer | BOOMX |
| Product category | A+ |
