One-legged semi-automatic turnstile
€1,275.00
Description
Turnstiles are the best tools for managing access control, allowing for easy and controlled entry and exit of individuals. They are suitable for office buildings, schools, factories, and hotels.
The TS-MTS1000N is a semi-automatic, single-leg, drop-arm turnstile. Thanks to its simpler mechanism, it is a more robust type. Its drop-arm design ensures that the arm automatically drops in case of an emergency or power outage. It features a brushed stainless steel housing. We offer long-term, even on-site warranty under contract. The device must be installed in a sheltered location.
Due to their design and operation, semi-automatic turnstiles are more durable, making them suitable for high-demand areas such as schools and factories. The drop-arm design provides free passage in case of an emergency or power outage.
Free delivery within Hungary!
| Materials needed for maintenance: | |||
 |
 |
 |
 |
|
BER-FEKTISZTITO Brake cleaner spray 500ml |
BER-INOXAPOLO Stainless steel care spray 400ml |
BER-UNISPRAY6+ Universal spray 400ml |
BER-HLS500 Lubricant spray 500ml |
| You can find the maintenance guide under the downloads section. | |||
Downloads
More Information
| Color | black |
|---|---|
| Voltage (V) | 230 V |
| Voltage type | AC |
| Power source capacity (A) | 6A @ 12V DC |
| Consumption (W) | 40 W |
| Body design | brushed INOX |
| Dimension of body | 320 x 950 x 250 mm |
| Arm size and type | 478 mm (brushed) |
| Arm cross section | ø38 mm |
| Arm load capacity | middle of arm 80 kg, end of arm 40 kg |
| Return by springs | yes (helps to take position) |
| Lockable? | automatically after rollover |
| Product family | semi-automat, normal-shape, turnstile |
| Opening possibilities | controlled electrical signal, (NO - dry contact, <1s) |
| Communication | RS485 (with BXC-SPIDER communicator) |
| Passage direction | one-way/two-way |
| Passing speed | 25 persons/min |
|---|---|
| Passing width | 550 mm |
| Emergency mode | in case of a power outage or emergency signal, it drops the arm |
| Built-in LED | above (dynamic) |
| Package contents | turnstile, arms, fixing screws (in concrete) |
| Compatible products | remote control module, BXC-SPIDER - RS485 communicator |
| Recommended use | medium traffic areas |
| Installation area | indoor, outdoor (rain-protected) |
| Life time | MCBF: 2 million turnovers |
| IP rating | IPx3 |
| Environmental temperature | -28°C ~ +60°C |
| Humidity tolerance (non-condensing) | 5 - 80% |
| Gross weight | 45 kg |
| Warranty | 24 months |
| Certificates | CE, FCC |
| Manufacturer | ZKTeco |
| Product category | B+ |
