SE-18
18-floor elevator control panel for the ST-680E central unit
€100.00
Description
SE-18 - 18-floor elevator control panel for the ST-680E central unit
Elevator control panels are ideal for regulating access to specific floors based on user credentials and time of access. After identification via a card or fingerprint reader inside the elevator, the pre-configured system determines which floors the user is authorized to access, enabling only the corresponding control buttons.
SE-18 is an 18-relay elevator control panel for the ST-680E elevator controller central unit. By connecting two of these panels, the system can manage up to 36 floors. It cannot be used on its own; the controller central unit is required for operation.
More Information
| Product category | H |
|---|---|
| Number of lock outputs | 18 |
| Number of Wiegand readers | 0 |
| Number of push button inputs | 0 |
| Number of door contact inputs | 0 |
| Number of auxiliary inputs | 0 |
| Number of auxiliary outputs | 0 |
| CAN BUS terminal | No |
| Design | metal housing |
| Programming | via free software (through the ST-680E controller unit) |
| Compatible software | SAC-100 |
| Handles biometric data | No |
| Opening methods | PIN, RFID, push button, software |
| Opening combinations | only card, only PIN, card or PIN, card and PIN |
|---|---|
| Timing of opening signal | 0 ~ 255 seconds |
| Bistable mode | No |
| Access control functions | timezone control, door left open alarm, remote door control |
| Calculates attendance time | No |
| Capacity | 9,000 users 6,000 events |
| Power supply | 12 V DC |
| Power consumption | 250 mA |
| Type of lock outputs | dry contact (NC/COM) |
| Dimensions | 145 × 210 × 50 mm |
| Other properties | only to be used with the ST-680E elevator central unit |
| Warranty (for legal entities) | 12 months |
| Certificate | CE |
| Manufacturer | SOCA-tech |
