0036 1 406 98 08
SKU
S7-BT
Drip-proof (IP66), standalone Bluetooth card reader - EM
€48.50
Description
S7-BT - Drip-proof (IP66), standalone Bluetooth card reader - EM
Standalone card readers are high-security devices suitable for controlling almost any access point. Their major advantage is that, beyond card identification, they can independently control door locks, eliminating the need for a separate door control panel in the system. Their installation and use are extremely simple.
S7-BT is an outdoor standalone card reader, a specialized version of the popular S7-EM model, now equipped with Bluetooth communication. It can be programmed with its dedicated remote control, but users can also be added or removed using a master card. While it primarily functions as a card reader, it can manage entry codes when connected to a keypad auxiliary reader.
Through Bluetooth, the device connects to the Tuya app, and with a WiFi bridge, it can be upgraded to WiFi capability, allowing for remote management and logging.
The package includes the reader, a remote control for programming, a master card, two screws with anchors for surface mounting, a diode for lock wiring, and a Torx key for removing the backplate.
More Information
| Product category | A |
|---|---|
| Type of device | RFID reader |
| Casing | metal case |
| Type of readable cards | EM |
| Readable frequency | 125 kHz |
| Keyboard | No |
| PIN length | 4 - 6-digit |
| Installation | surface-mounted |
| Installation environment | outdoor (with rain protection) |
| Environmental protection rating | IP66 |
| Vandalproof protection | metal case, sabotage protection |
| Capacity | 1,000 users (990 normal, 10 guest) |
| Method of security backup | none |
| Methods of adding users | via master cards, via remote control |
| Communication methods | can manage Wiegand reader, can work as Wiegand reader, Bluetooth |
| Wiegand input bit rating | 26/34 bit |
| Wiegand output bit rating | 26 bit |
| Power supply | 12-24 V DC |
| Power consumption | 60 mA (idle); 150 mA (active) |
| Dimensions | diameter: 73 mm depth: 20 mm |
| Reading range | 2 ~ 6 cm |
| Language of internal menu | none |
|---|---|
| LED | Yes |
| Buzzer | Yes |
| Keyboard lighting | no |
| Number of controllable doors | 1 |
| Lock output type | dry contact (relay, NO/NC/COM) |
| Lock output load capacity | 2 A |
| Inputs | push button, Wiegand |
| Outputs | Wiegand |
| Tamper protection | yes (via optical sensor) |
| Opening methods | only card, only PIN, card and PIN, card or PIN |
| Opening signal length (if used in timed mode) | 1 ~ 99 seconds |
| Bistable mode | Yes |
| Access control functions | normal, multicard opening, open with guest PIN (PIN that can onbly be used x times)), open with guest card (card that can onbly be used x times)) |
| Events that cause alarm | multiple failed PIN attempts, multiple failed card attempts, tamper |
| Alarm timing | 0 ~ 3 minutes |
| Display | No |
| Working temperature | -40°C ~ +60°C |
| Humidity tolerance | 0% ~ 98% (non condensing) |
| Other properties | Bluetooth-enabled control with the Tuya app, and remote access via WiFi when using a WiFi bridge |
| Warranty (for legal entities) | 12 months |
| Certificate | CE |
