Wiegand proximity auxiliary readers are suitable devices for complementing high-security access control systems. The Wiegand standard is extremely simple, allows cabling up to 50 meters, and is one of the most widespread interfaces in access control systems.
KR-300DUAL is a indoor Wiegand reader with keyboard with aesthetic plastic housing and 26- or 34-bit communication, capable of reading both 125 kHz EM and 13.56 MHz MIFARE cards. It features LED feedback and a buzzer. Ideal solution for complementing almost any small or large access control or time & attendance system.
Product category | A |
---|---|
Readable cards | 125 kHz EM, 13.56 MHz MIFARE |
Communication | Wiegand |
Casing | plastic |
Wiegand output bit rating | 26/34 bits |
Reading range | 3 ~ 10 cm |
Biometric identification | No |
Has keyboard | No |
Keyboard lighting | No |
LED | Yes |
Buzzer | Yes |
Protection rating | IP65 |
---|---|
Installation environment | outdoor (without protection) |
Installation | surface-mounted |
Power supply | 6-14 V DC |
Power consumption | 70 mA |
Dimensions | 77.55 × 42.8 × 16.5 mm |
Working temperature | -10°C ~ +70°C |
Humidity tolerance | 10% ~ 90% |
Warranty (for legal entities) | 12 months |
Certificate | CE, DOC, RoHS, FCC |
Manufacturer | ZKTeco |
