0036 1 406 98 08
SKU
ABK-901-12-3
Regulated power supply - 12 V DC 3 A
€36.50
Description
Regulated Power Supply 12V DC 3A
The ABK-902-12-3 is a regulated power supply, ideal for powering locks, card readers, access control devices, etc. It has a 12V DC output voltage with a maximum load of 3A. It has automatic short circuit protection, timer, lock control output and pushbutton input.
Downloads
More Information
| Voltage (V) | 200 - 240 V |
|---|---|
| Voltage type | AC |
| Output voltage | 12V DC |
| Controlled output type | switched voltage |
| Controlled output timing | adjustable (0-30 s) |
| Power source capacity (A) | 3A @ 12V DC |
| Continuous power (W) | 36 W |
| Type of connection | screw connection |
| Product family | transformer power supply, controlled power supply |
| Dimensions | 180 x 79 x 63 mm |
| Type of control | push button (dry contact) |
|---|---|
| Other functions | LED indication, protected in- and output, short-circuit protection |
| Recommended use | for powering security and access control systems, for controlling electric locks |
| Installation area | indoor, covered, dry areas |
| Environmental temperature | -10°C ~ +55°C |
| Humidity tolerance (non-condensing) | max. 95% |
| Gross weight | 1,4 kg |
| Warranty | 12 months |
| Certificates | CE |
| Product category | A |
