0036 1 406 98 08
SKU
SPHD1203-01B
Uninterruptible Power Supply in a Screw-Lockable Box, 13.8 V DC, 3A
€29.00
Description
The SPHD1203-01B is a DIN rail-mounted uninterruptible power supply designed to provide power for access control systems, locks, and surface-mounted magnets. It features adjustable output voltage and can handle a maximum load of 3 A. It comes equipped with automatic short-circuit protection and deep discharge protection.
WARNING! Use only in covered, dry locations!
Downloads
More Information
| Voltage (V) | 190 - 265 V |
|---|---|
| Voltage type | AC |
| Output voltage | 13,8V DC |
| Power source capacity (A) | 3A + 0,65 töltés @ 13,8V DC |
| Continuous power (W) | 50 W |
| Efficiency | ~88% |
| Type of connection | screw connection |
| Product family | switching power supply |
| Dimensions | 228 x 195 x 78 mm |
| Other functions | uninterruptable, LED indication, protected in- and output, filtered output, short-circuit protection, deep discharge protection |
| Recommended use | for powering security and access control systems |
| Mounting | surface mounted |
|---|---|
| Installation area | indoor, covered, dry areas |
| Compatible products | batteries |
| Battery charging current | 0.65 A (decreases as the battery voltage increases) |
| Recommended battery replacement cycle | 1 year in security technology applications |
| Storage conditions | -30°C ~ +80°C |
| Environmental temperature | -20°C ~ +50°C |
| Humidity tolerance (non-condensing) | 20% ~ 80% |
| Gross weight | 0,85 kg |
| Warranty | 12 months |
| Certificates | CE |
| Product category | A |
