SKU
BXA-GSM-524-4G
4G GSM module with 1 channel
€95.00
Description
The BXA-GSM-524-4G is a remote control module via GSM 4G network with relay. Easy to operate by phone call and configurable SMS commands.
The device supports up to 200 users with permanent or individually restricted access over a date/time interval. The device can be used to control the automation of gates, garage doors, car barriers, dock shelters, electric motors, street lighting or other contact-operated electrical appliances. The operation is performed by a cost-free voice call, the module rejects the call after identifying the caller.
Downloads
More Information
| Product category | F |
|---|---|
| Power supply | 9-24 V DC |
| Wiring type | via terminal block |
| Number of channels | 1 |
| Output type | NO/NC/COM |
| Output load capacity | 3 A @ 240 V AC |
| Opening signal type | timed, bistable |
| Opening signal length (if used in timed mode) | 0,5-998 sec |
| Communication | GSM |
| Mobile app | No |
|---|---|
| SIM card | Yes |
| SIM type | 1FF normal size |
| User capacity | 200 simultaneous users |
| LED | No |
| Other properties | Dimensions: 102 x 76 x 27 mm |
| Warranty (for legal entities) | 12 months |
| Certificate | CE |
| Manufacturer | BOOMX |
