0036 1 406 98 08
SKU
WBK-400B
Two-button wall-mounted remote control with fixed code
€23.00
Description
The WBK-400B is a two-button, wall-mounted, fixed code remote control with the aesthetic design of a traditional switch.
It can be used as an add-on to several WBK-4xx remote control transceiver sets when some kind of control needs to be solved from a fixed location. There are two push buttons below the toggle switch, with the right (LED side) button being button 1 and the left button being button 2. The package includes a separate battery for the device, not included as with other portable remote controls. (The screws for mounting are NOT included with the device!)
Downloads
More Information
| Voltage (V) | 6 V |
|---|---|
| Voltage type | battery |
| Power supply requirement | permanent |
| Operation frequency | 433.92 MHz |
| RF code type | Fix code |
| Antenna type | Panel antenna |
| Tamper protection | none |
| Installation area | indoor |
| Housing material | plastic ABS |
| Environmental temperature | -10°C - +50 °C |
| Humidity tolerance (non-condensing) | max. 95% |
| IP rating | unclassified |
| IK rating | None |
| Gross weight | 46 gr |
| Package contents | 1 pc remote control with battery |
|---|---|
| Warranty | 12 months |
| Certificates | CE |
| Manufacturer | YLI |
| Number of buttons on remote control | 2 |
| Remote control layout | Fixed installation |
| Remote control button protection | None |
| Compatible receivers | AJ-84-2, WBK-400-1-12, WBK-400-2-12/24, WBK-401-1-12, WBK-401-2-12/24 |
| Remote control functions | Controls, Panic |
| Type of remote control battery | 1x LR11A |
| Suggested battery replacement cycle time | 1 year |
| Remote control antenna power (mW) | 10 mW |
| Modulation | ASK |
| Remote control dimensions | 80 x 80 x 16 mm |
| Product category | A |
