0036 1 406 98 08
SKU
SG-26-RG
Electromagnet controller - 12V AC/DC - flush muntable - timing - NO/NC output
€45.80
Description
The SG-26-RG is a surface magnet control device capable of impulse, timed, and bistable operating modes, and features light and sound feedback. Its maximum load capacity is 2A at 30V DC. It has independent NO (Normally Open) and NC (Normally Closed) dry contact outputs.
Downloads
More Information
| Product category | A |
|---|---|
| Installation mode | surface mountable |
| Installation area | into protected area |
| Power supply | 12 V DC |
| Current consumption | 19 mA (12 V DC) |
| Power | 0,2 W |
| Dimensions | 115 x 40 x 36 mm |
| Timing | 0 - 60 mp |
| Pushbutton type | microswitch |
|---|---|
| LED colour | green |
| Buzzer | Yes |
| Built-in cylinder | No |
| Output signal type | NO/NC/COM |
| Output load capacity | 2A@30 V DC |
| Warranty (for legal entities) | 12 months |
| Certificates | CE |
| Manufacturer | YLI |
