0036 1 406 98 08
SKU
DORCAS-48-NF-512-L
Electric strike for security doors - 12V DC - fail-safe - DIN Left - without faceplate
€100.00
Description
|
Electric strikes are the most widespread solution for electric door locking, thanks to their versatility in being suitable for almost any type of door. DORCAS is a Spanish manufacturer with an extremely wide range of products, offering high-quality electric locks. The DORCAS-48 series comprises electric strikes specifically designed for DORCAS security doors. The device operates in a fail-safe mode, meaning it requires power to be locked. This product is suitable for left-handed doors. For right-handed doors, choose the DORCAS-48-NF-512-R model. MAINTENANCE! Regular inspection of the mechanics of electric strikes (refreshing lubrication) is necessary to ensure optimal operation. |
||||
 |
 |
 |
 |
 |
Downloads
More Information
| Voltage (V) | 12 V |
|---|---|
| Voltage type | DC |
| Maximum current consumtion (A) | 180 mA (12 V DC) |
| Resistance (Ω) | 70 Ω |
| Power consumption (W) | 2,16 W |
| Power comsumption on opening (W) | 0 W |
| Power comsumption on closing (W) | 2,16 W |
| Expected per year consumption (kWh) | 18,9 kWh |
| Breaking point (N) | 3383 N |
| Breaking point (kgf) | 345 kgf |
| Operating modes | needs power to close |
| Type of control | power cut |
| Opening possibilities | controlled electrical signal |
| Behaviour (in case of power off) | Fail-safe |
| Product family | 48 - for armoured and reinforced doors |
| Low power consumption? | yes ( ≤ 260 mA ) |
| Simmertical? | no |
| Narrow? | no |
| Mini? | no |
| Radial latch? | yes |
| Opening memory? | no |
| Flexibile jaw? | yes (+2 /- 1 mm) |
|---|---|
| Unlock feature? | no |
| Latch monitoring | no |
| Opening direction (DIN 107) | DIN L |
| Field of use | interior door, entrance doors |
| Mounting | flush mounted |
| Related faceplates | DORCAS-W-gy |
| Installation area | indoor |
| Preloaded door opening | no |
| Dimensions | 89 x 23 x 33 mm |
| Distance between fixing holes | 40,5mm | 45 mm |
| Life time | 300.000 opening |
| IP rating | unclassified |
| Environmental temperature | -25°C ~ +50°C |
| Common installation errors | Az elektromos zár kenésének javítására vagy megújítására a WD40 oldó és korrózió eltávolító spray nem alkalmas, használata TILOS! |
| Voltage drop | ATTENTION! The proper operation of the device is highly sensitive to voltage drop. The lock must be supplied with a stable 12 V DC power source. |
| Gross weight | 0,25 kg |
| Warranty | 36 months |
| Certificates | CE |
| Manufacturer | DORCAS |
| Product category | A |
