0036 1 406 98 08
SKU
DORCAS-SW99-2-NDF+25C
Waterproof electric strike - fail-secure - unlock feature - adjustable jaw - without faceplate
€66.00
Description
|
Electric strikes are the most widespread solution for electric door locking, thanks to their versatility in being suitable for almost any type of door. DORCAS is a Spanish manufacturer with an extremely wide range of products, offering high-quality electric locks. The DORCAS-SW-99 series comprises DORCAS's waterproof (IP68), low-profile, narrow strikes with radial latch, making them ideal for narrow door frames. The device operates in a fail-secure mode, meaning it requires power to unlock. The device features an IP68 protection rating. Based on available tests, when submerged in water at a depth of 1.5 meters for 3 hours, it retained its functionality. The device is available with a 250 mm long cable, designed for connection in a way that maintains its IP68 protection rating. ATTENTION! The device only achieves the IP68 protection rating when placed under voltage with the factory cable. Connect the cable only once with great care, ensuring that the two connector pins are not damaged. MAINTENANCE! Regular inspection of the mechanics of electric strikes (refreshing lubrication) is necessary to ensure optimal operation. |
|||
 |
 |
 |
 |
 |
 |
 |
 |
More Information
| Voltage (V) | 10 - 24 V |
|---|---|
| Voltage type | AC/DC |
| Maximum current consumtion (A) | 280 mA (12V DC) |
| Resistance (Ω) | 43 Ω |
| Power consumption (W) | 3,36 W |
| Power comsumption on opening (W) | 3,36 W |
| Power comsumption on closing (W) | 0 W |
| Expected per year consumption (kWh) | 0,03 kWh |
| Breaking point (N) | 3236 N |
| Breaking point (kgf) | 330 kgf |
| Operating modes | needs power to open |
| Type of control | timed pulse (1~15 s) |
| Opening possibilities | controlled electrical signal |
| Behaviour (in case of power off) | Fail-secure |
| Product family | SW99 - waterproof, mini |
| Low power consumption? | yes ( ≤ 300 mA ) |
| Simmertical? | yes |
| Narrow? | yes |
| Mini? | yes |
| Radial latch? | yes |
| Opening memory? | no |
| Flexibile jaw? | yes (+3 / 0 mm) |
| Unlock feature? | yes |
|---|---|
| Latch monitoring | no |
| Opening direction (DIN 107) | universal |
| Field of use | outdoor gates, gates |
| Mounting | flush mounted |
| Package contents | 250 mm cable special with connector |
| Related faceplates | DORCAS-BX-22, DORCAS-EZR-22-gy, DORCAS-LX-22, YSHB-08-L/R, DORCAS-GU-L/R |
| Compatible jaw | DORCAS-JAW-99-2-N, DORCAS-JAW-99-2-N-MIM |
| Installation area | outdoor |
| Preloaded door opening | no |
| Dimensions | 66 x 16,5 x 25,5 mm |
| Distance between fixing holes | 52,5 mm |
| Life time | 200.000 opening |
| IP rating | IP68 |
| Environmental temperature | -25°C ~ +50°C |
| Common installation errors | Az elektromos zár kenésének javítására vagy megújítására a WD40 oldó és korrózió eltávolító spray nem alkalmas, használata TILOS! |
| Voltage drop | ATTENTION! If the cable connector is oriented downward during installation, the lock’s performance may be significantly impacted by voltage drop effects |
| Gross weight | 0,13 kg |
| Warranty | 36 months |
| Certificates | CE |
| Manufacturer | DORCAS |
| Product category | A |
