0036 1 406 98 08
SKU
DORCAS-87-N-512(S)
Electric strike for frameless glass doors - 12V DC - fail-safe - DIN Right - with faceplate
€138.00
Description
|
Electric strikes are the most widespread solution for electric door locking, thanks to their versatility in being suitable for almost any type of door. DORCAS is a Spanish manufacturer with an extremely wide range of products, offering high-quality electric locks. The DORCAS-87 series is designed for securing the closing of fraqmeless glass doors. The device operates in a fail-safe mode, meaning it requires power to be locked. DORCAS electric strikes should always be installed indoors, in a place well protected from rain. If you are looking for an electric strike suitable for outdoor installation, the waterproof series models are the right choice. MAINTENANCE! Regular inspection of the mechanics of electric strikes (refreshing lubrication) is necessary to ensure optimal operation. |
|||
 |
 |
 |
 |
More Information
| Voltage (V) | 12 V |
|---|---|
| Voltage type | DC |
| Maximum current consumtion (A) | 170 mA |
| Resistance (Ω) | 70 Ω |
| Power consumption (W) | 2,04 W |
| Power comsumption on opening (W) | 0 W |
| Power comsumption on closing (W) | 2,04 W |
| Expected per year consumption (kWh) | 0,02 kWh |
| Breaking point (N) | 2500 N |
| Breaking point (kgf) | 255 kgf |
| Operating modes | needs power to close |
| Type of control | power cut |
| Opening possibilities | controlled electrical signal |
| Behaviour (in case of power off) | Fail-safe |
| Product family | 87 - glass doors with frame |
| Low power consumption? | yes ( ≤ 260 mA ) |
| Simmertical? | no |
| Narrow? | no |
| Mini? | no |
| Radial latch? | no |
| Opening memory? | no |
| Flexibile jaw? | no |
|---|---|
| Unlock feature? | no |
| Latch monitoring | no |
| Opening direction (DIN 107) | universal |
| Field of use | frameless glass doors |
| Mounting | flush mounted |
| Package contents | faceplate (short) |
| Installation area | indoor |
| Preloaded door opening | no |
| Dimensions | 105 x 21 x 28 mm |
| Distance between fixing holes | 52,5 mm |
| Dimension of faceplate | 160 x 25 x 3 mm |
| Life time | 250.000 opening |
| IP rating | unclassified |
| Environmental temperature | -25°C ~ +50°C |
| Common installation errors | Az elektromos zár kenésének javítására vagy megújítására a WD40 oldó és korrózió eltávolító spray nem alkalmas, használata TILOS! |
| Voltage drop | ATTENTION! The proper operation of the device is highly sensitive to voltage drop. The lock must be supplied with a stable 12 V DC power source. |
| Gross weight | 0,33 kg |
| Warranty | 36 months |
| Certificates | CE |
| Manufacturer | DORCAS |
| Product category | A |
