PRED-ENT-EVA+100 - Predor disaster response module expansion (+100 users)
Predor is a Hungarian-developed system, and although its foundation is simple door control (and closely related functions), it is capable of much more and can be customized according to specific requirements. The system's software essentially has two versions, Lite and Enterprise, which differ in terms of features, pricing, and expandability.
The Lite version is essentially the offline version of Predor, which requires a license but is free for up to 20 users and does not have functions requiring global communication between multiple panels. This version can only be expanded with modules that have functions usable in offline mode, and if these modules have online functions, those functions are not accessible in Lite. While the number of doors is unlimited, the number of clients is limited to 1. The number of users can be increased by purchasing expansion licenses for 10, 100, and 500 additional users.
In contrast, the Enterprise is the online version of Predor, which requires a server, but which provides access to the full range of the main system's functions, as well as the option to purchase all possible modules for customization purposes. Unlike in Lite, in Enterprise, both the number of doors and clients are unlimited, but even the base license is not free. Similarly to Lite though, the base license can be used for up to 20 users, and expansion licenses for 10, 100, or 500 additional users can be purchased.
Most modules, like the main versions, handle 20 users by default but can also be expanded with 10-, 100-, and 500-user expansion licenses. Each module requires the main software, but it is not always necessary to expand the main software to the same extent as the additional module. This is only important in cases where the user base of the additional module is essentially the same as that of the main software, such as for example is the case for the time attendance module.
A PRED-ENT-EVA+100 is the expansion of the Predor evacuation module for an additional 100 users. With its purchase, the number of individuals manageable in evacuation plans increases by an additional 100 beyond the previous limit. The system can be further expanded with additional expansion licenses. As it is an online feature, it only operates with Predor Enterprise version.
To activate it, you must already have the base module (PRED-ENT-EVA) as well as the basic license of Predor Enterprise (PRED-ENT-AC). Additionally, since the module works with the users of the main system, it is necessary to expand the main software to match the number of users in the evacuation module.
*small system: about 1-2 access control panels, 10-20 users and 100-200 events daily
**medium system: about 10 access control panels, 100 users and 2,000 events daily
***big system: about 50 access control panels, 1,000 users and 10,000 events daily
Product category | D+ |
---|---|
Software function | evacuation control |
Supported operating systems | Windows 8.1, Windows 10 (64 bit), Ubuntu 20.04 LTS (64 bit) |
Runtime environment | desktop application |
Minimal CPU requirement | 2-core 2 GHz, eg. Intel Core i3 or equal (small system*) 2-core 2 GHz, eg. Intel Core i3 or equal (medium system**) 8-core 2.9 GHz, eg. Intel Core i7 or equal (big system***) |
Minimal RAM requirement | 4 GB DDR3 (small system*) 8 GB DDR3 (medium system**) 16 GB DDR4 (big system***) |
Minimal HDD requirement | 10 GB (small system*) 100 GB (medium system**) 100 GB (big system***) |
Minimal display resolution | 1366 × 768 |
Minimal network requirement | 100 Mbit Ethernet (small system*) 1000 Mbit Ethernet (medium system**) 1000 Mbit Ethernet (big system***) |
---|---|
Optimal CPU requirement | 4-core 2.4 GHz, pl. Intel Core i5 or equal (small system*) 4-core 2.4 GHz, pl. Intel Core i5 or equal (medium system**) 16-core 2.3 GHz, pl. Intel Xeon Gold 6140 or equal (big system***) |
Optimal RAM requirement | 8 GB DDR3 (small system*) 8 GB DDR4 (medium system**) 32 GB DDR4 (big system***) |
Optimal HDD requirement | 100 GB (small system*) 100 GB (medium system**) 200 GB (big system***) |
Optimal display resolution | 1920 × 1080 |
Optimal network requirement | 1000 Mbit Ethernet (small system*) 1000 Mbit Ethernet (medium system**) 1000 Mbit Ethernet (big system***) |
Licence informations | unlimited doors, +100 users beyond the previous limit, unlimited clients |
Manufacturer | Predor |
